ESB Chest display slot dimensions question

[slavedriver]

Can anyone point me in the correct direction for getting the correct dimensions for my ESB chest display cutouts? I just want to make sure I check twice but only have to cut once if you know what Im saying. Many thanks



[LostDreams]

http://www.thedentedhelmet.com/f20/all-boba-fett-armor-stencils-templates-23196/

This has a few templates for the types of armor that may match the size of armor you have or may be getting (whichever the case may be)

The next one has the exact measurements in MM's for the display on NemesisCustoms post in the CH.

http://www.thedentedhelmet.com/f31/boba-chest-display-deluxe-56004/?highlight=chest+display

Hopefully that's at least a step in the right direction, or all that you need



[slavedriver]

Thank you very much



[Gregory]

More importantly, get your display and make sure the cutouts fit your display. My display just barely fits (is a little tight) in my cutouts.



[redkraytdragon]

I can't echo that enough. Don't cut your slots out until you have the chest display in hand.



[toofastrobot]

More importantly, get your display and make sure the cutouts fit your display. My display just barely fits (is a little tight) in my cutouts.

The chest lights are supposed to sit just behind the slots, not be placed into them. I'm not sure if that's what you meant, but that's how I interpreted your post



[Gregory]

The chest lights are supposed to sit just behind the slots, not be placed into them. I'm not sure if that's what you meant, but that's how I interpreted your post

Yes, that's what I meant too, but the openings have to match the display dimensions.



[jbdubz]

Yes, that's what I meant too, but the openings have to match the display dimensions.

actually, the chest display windows are smaller than the chest light themselves. they are a bit cut off on the right side (facing), both top and bottom windows.

Sent from my iPhone



[slavedriver]

Thanks guys for all the imput and the pics. Excellent help as usual
