ABS edge cutting Fett ROTJ

InvogueUK

New Hunter
Cracking on with the Fett ROTJ build I am now cutting out the rough ABS parts. One question is on the 501st CRL it says
Costuming:BH Boba Fett-RotJ - Databank

"
  • Must have a return edge, giving the feeling of thickness and depth."
How thick should this edge be for the chest?



InvogueUK

New Hunter
Thanks, I'll err on the side of caution so 5mm. I have a belt sander outside and I am shaving off most excess today. I want to get it ready for undercoat this week so I can start painting next week.
BTW it's all from RS Propmasters.


InvogueUK

New Hunter
Is the edge thickness for the cod, kidney, knees and back the same 5mm? I'm cutting the with the dremel right now and I am not seeing any guide lines. A crucial stage I don't want to mess up.


TheZeroEffect

Active Hunter
If remember right, I did all mine at 3mm, 5 just seemed too thick to me.
That includes all plates, I also fold over the top edge on the back plate so it looked more like rolled metal (the neck area that stick up a little)


InvogueUK

New Hunter
If remember right, I did all mine at 3mm, 5 just seemed too thick to me.
That includes all plates, I also fold over the top edge on the back plate so it looked more like rolled metal (the neck area that stick up a little)
Ok thanks, I have cut mine all at 5mm. The dremel went a little in at some parts anyway so I will use sandpaper to get it all perfect around 3-4mm to finish. This is the second cut, third will be final finishing before washing, sanding and undercoat... All this week hopefully.


Funkyred

Hunter
It mite be any idea to backfill the reverse of the knees with fibreglass to stiffen then up , before that you can heat the knees up with a hairdryer to shape them around the knee so they fit more snuggly


InvogueUK

New Hunter
It mite be any idea to backfill the reverse of the knees with fibreglass to stiffen then up , before that you can heat the knees up with a hairdryer to shape them around the knee so they fit more snuggly
Good tip - I hear the knees don't last long as ABS only. And I will try the hairdryer when I need to get them on. I've just been putting on the initial coat of Humbrol 11 to the lid. First coat applied, I'll do another tomorrow.
